TOUCHLESS HMI

HG SERIES

An infrared gesture sensor that enables reliable operation without touching the terminal. Ideal for public-facing, industrial, and medical environments.

The HG Series detects hand movements in front of the screen using an integrated infrared gesture sensor. By recognizing the direction and motion of a user’s hand, the system enables intuitive, touch-free operation, no physical contact with the display required.

This touchless interface reduces contamination risk, improves hygiene, and allows reliable operation in environments where gloves, moisture, or frequent contact make traditional touchscreens impractical.

  • More Freedom. Smarter Operation in the Field.

    Operate equipment using simple hand gestures—no touch required.
    Vertical hand motions enable up-and-down scrolling, horizontal motions control left-and-right navigation, and a hover gesture performs ENTER commands. The HG gesture device unlocks new operating possibilities in environments where touch is impractical, delivering a smoother, more intuitive user experience through natural hand movement alone.

    Simple Installation. No Configuration Required.

    Get up and running instantly with a single USB Type-C connection.
    No setup or calibration is required—just connect the device and mount it using the standard Φ22.3 mm panel hole with rear screw fastening. Designed for easy retrofitting, the HG Series installs quickly on existing equipment and immediately improves on-site workflow.

    IP65-Equivalent Protection for Harsh Environments.

    Built to perform in demanding conditions.
    The HG Series features an IP65-equivalent dustproof and drip-proof design, offering strong resistance to water, moisture, sand, and dust. Suitable for outdoor installations, factories, and industrial environments, it delivers reliable operation even in heavy rain or dusty conditions.

    Fully Customizable Operation.

    Tailor the device to your application.
    Using the HG Setting Tool, you can adjust LED colors and patterns, modify sensor sensitivity*, and configure temporary lock settings. Gesture inputs are transmitted to the host as standard keyboard keycodes, allowing easy integration and flexible customization without additional software development.

    * Detection distance cannot be changed.Description text goes here

  • Product Name: HG-RL6U2C01
    Dimensions (W × H × D): 130 × 60 × 16 mm
    Body Color: Black
    Weight: Approx. 110 g

    Power & Sensor

    Power Supply Voltage: DC 5V
    Sensor: Infrared rays
    Sensor Type: Gesture sensor

    Gesture Detection

    Detection Range: 0–15 cm (recommended 5–15 cm)
    Viewing Angle (Diagonal): 60°

    Environmental Specifications

    Operating Temperature: 0–55 °C
    Operating Humidity: 10–80% RH
    Storage Temperature: −20 to +60 °C
    Storage Humidity: 10–80% RH

    Mounting & Interface

    Panel Cutout Diameter: Φ22.3 mm (+0.3 / −0)
    Interface: USB Type-C

    Protection & Indicators

    Protection Structure: IP65-equivalent (front surface)
    LED Display: RGB (24-bit), 6 LEDs

    Certifications

    Compliance Standards: CE / UL / FCC

    Notes

    Connection cable is not included. Please contact our sales representative for details.
