RESISTIVE TOUCHSCREEN

Resistive touchscreens register input through pressure applied to two opposing ITO layers, delivering consistent and reliable performance. Long trusted in industrial applications such as ATMs and ticket machines, they operate accurately with gloves, pens, or bare hands, making them well suited for harsh or controlled environments.

Smartphone-Like Operation with Resistive Touchscreen

Light-Load Type

LST Series

  • Smartphone-like operation is achieved by leveraging the advantages of resistive touch technology, enabling intuitive gestures such as flick input.

    Available sizes:
    4.3w, 5.7, 7w, 8.4, 6.5, 10.1w, 10.4, 12.1, 12.1w, 15, 15.6w, 18.5w, 19, 21.5w

    By integrating the touchscreen with an LCD display, touch functionality can be easily added to your product. When incorporated into development devices, it enables a high-quality, intuitive HMI. Combined with DMC’s proprietary controllers, the touchscreen can be finely tuned to specific operating environments, including glove operation and weather-resistant use cases.

  • 4.3 inch — LST-043WC080C (Built to Order)

    Tail Length / Pin Pitch / Position: 80 / 1 / Lower Side
    Dimensions (mm):

    • Outline (E): 105.4 × 67.83

    • View Area (V): 97.54 × 55.86

    • Active Area (A): 95.54 × 54.36

    Glass / Total Thickness: 1.1 / 1.4 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    5.7 inch — LST-057C080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 131.4 × 103

    • View Area (V): 119.7 × 90.9

    • Active Area (A): 115.7 × 86.9

    Glass / Total Thickness: 1.1 / 1.4 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    6.5 inch — LST-065C080C (Built to Order)

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 147.3 × 114.3

    • View Area (V): 136.98 × 103.86

    • Active Area (A): 132.98 × 99.86

    Glass / Total Thickness: 1.1 / 1.4 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    7.0 inch (Wide) — LST-070WC080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 165.15 × 104

    • View Area (V): 155.9 × 94.94

    • Active Area (A): 152.9 × 91.94

    Glass / Total Thickness: 1.1 / 1.4 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    8.4 inch — LST-084C080C (Built to Order)

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 185.6 × 143.3

    • View Area (V): 174.9 × 132.3

    • Active Area (A): 170.9 × 128.3

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    10.1 inch (Wide) — LST-101WC080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 234.7 × 153

    • View Area (V): 221.46 × 140.1

    • Active Area (A): 217.46 × 136.1

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    10.1 inch (Wide, WS) — LST-101WC080C-WS (Built to Order)

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 236.27 × 143

    • View Area (V): 227.22 × 129.78

    • Active Area (A): 223.22 × 125.78

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    10.4 inch — LST-104C080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 227.6 × 175.4

    • View Area (V): 215.7 × 162.9

    • Active Area (A): 211.7 × 158.9

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    12.1 inch — LST-121C080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 263 × 201

    • View Area (V): 250.5 × 189

    • Active Area (A): 246.5 × 185

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    12.1 inch (Wide) — LST-121WC080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 278.4 × 180.7

    • View Area (V): 265.62 × 167.7

    • Active Area (A): 261.62 × 163.7

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    15.0 inch — LST-150C080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 328 × 252

    • View Area (V): 308.63 × 232.6

    • Active Area (A): 304.63 × 228.6

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-S1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    15.6 inch (Wide) — LST-156WC080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 361.5 × 210.2

    • View Area (V): 348.73 × 198.04

    • Active Area (A): 344.73 × 194.04

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-L1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    18.5 inch (Wide) — LST-185WC080C (Built to Order)

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 428.5 × 250

    • View Area (V): 414.3 × 234.9

    • Active Area (A): 410.3 × 230.9

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-L1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    19.0 inch — LST-190C080C (Built to Order)

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 400.6 × 326.4

    • View Area (V): 380.8 × 305.6

    • Active Area (A): 376.8 × 301.6

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-L1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    21.5 inch (Wide) — LST-215WC080C

    Tail Length / Pin Pitch / Position: 80 / 1 / Left Side
    Dimensions (mm):

    • Outline (E): 500 × 293.2

    • View Area (V): 480.56 × 272.29

    • Active Area (A): 476.56 × 268.29

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controllers: TSC-52/RU-F-L1, TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

  • CLICK TO SEE THIS PRODUCT IN THE DMC STORE

High Visibility & Serviceable High-Spec Model

Enhanced Type

QST Series

  • Fingerprint-resistant and easy on the eyes, this touchscreen combines anti-glare treatment with high-definition clarity and a light-touch operating feel.

    Available sizes:
    5.7, 7w, 8.4, 8.5w, 10.4, 12.1, 15

    This high-performance 4-wire resistive touchscreen features an anti-humidity tail that reduces the visibility of fingerprints and maintains clear display quality. Pressure-sensitive input ensures stable, noise-free operation, allowing reliable use with gloves or a pen in demanding environments.

  • 5.7 inch — QST-057A075H

    Tail Length / Pin Pitch / Position: 75 / 1 / Left Side

    Dimensions (mm):

    • Outline (E): 131.4 × 103

    • View Area (V): 118.4 × 89.9

    • Active Area (A): 116.4 × 87.9

    Glass / Total Thickness: 1.1 / 1.4 mm
    Compatible Controller: TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    7.0 inch (Wide) — QST-070WA075H

    Tail Length / Pin Pitch / Position: 75 / 1 / Left Side

    Dimensions (mm):

    • Outline (E): 165 × 104

    • View Area (V): 154.9 × 93.94

    • Active Area (A): 152.4 × 91.44

    Glass / Total Thickness: 1.1 / 1.4 mm
    Compatible Controller: TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    8.4 inch — QST-084A075H

    Tail Length / Pin Pitch / Position: 75 / 1 / Left Side

    Dimensions (mm):

    • Outline (E): 183.7 × 141.1

    • View Area (V): 172.4 × 129.8

    • Active Area (A): 170.4 × 127.8

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controller: TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    8.5 inch (Wide) — QST-085WA075H (Built to Order)

    Tail Length / Pin Pitch / Position: 75 / 1 / Left Side

    Dimensions (mm):

    • Outline (E): 194.9 × 128.6

    • View Area (V): 185.9 × 114.9

    • Active Area (A): 183.9 × 111.7

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controller: TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    10.4 inch — QST-104A075H

    Tail Length / Pin Pitch / Position: 75 / 1 / Left Side

    Dimensions (mm):

    • Outline (E): 227.6 × 175

    • View Area (V): 215.2 × 162.4

    • Active Area (A): 211.2 × 158.4

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controller: TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    12.1 inch — QST-121A075H

    Tail Length / Pin Pitch / Position: 75 / 1 / Left Side

    Dimensions (mm):

    • Outline (E): 263 × 201

    • View Area (V): 250 × 188.5

    • Active Area (A): 247 × 185.5

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controller: TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

    15.0 inch — QST-150A075H

    Tail Length / Pin Pitch / Position: 75 / 1 / Left Side

    Dimensions (mm):

    • Outline (E): 328 × 252

    • View Area (V): 309 × 233

    • Active Area (A): 305 × 229

    Glass / Total Thickness: 1.8 / 2.1 mm
    Compatible Controller: TSC-54/RU-F

    2D and 3D drawings (PDF, DXF, STEP) are available upon request.

  • CLICK TO SEE THIS PRODUCT IN THE DMC STORE
